| Force | 20 kN 40 kN |
| Power | 1.5 KW |
| Cross Section Range | Up to 10 mm2 (Material thickness up to 0.8mm) |
| Stroke | 121.7mm / 135.788 mm |
| Stroke | 30 mm / 40mm |
| Adjusting range | 10mm |
| Stroke per minute | 160 -200s.p.m |
| Press Activation | Foot Pedal |
| Noise Level | < 70 dB (A) |
| Power | 220VAC, 50/60 Hz |
| Capacity | Max. 750 VA |
| Dimensions (L x W x H) | 360 x 350 x 800 mm |
| Weight | 80 kg |
