Automatic Wire Cut and Strip Machine adopts ARM high-speed processor, combined with advanced motion control technology. Wire stripping machine is a new generation of wire harness processing equipment with independent intellectual property rights.
ESC-BX9 adopts advanced human-computer interface, humanized design, and it is very simple to operate. The processed wire harness has the same length, beautiful appearance and good effect.
| Model | ESC-BX9 |
| Wire diameter | Max. φ8 mm |
| Max. cable cross section standard | 0.1-6.0mm²(Min.AWG 32) |
| Applicable wire type | Single core wire |
| Cutting length | 0.1-99999.9mm |
| Stripping length | Front stripping: 0.1－30mm; Rear stripping: 0.1-30mm |
| Stripping length of inner wire | Lenght1: 0.1-15mm; Length2: 0.1-15mm |
| Cutting tolerance | Within 0.002×L (mm) |
| Production capacity | 3000-6000 pieces (adjusted and changed according to actual wire material) |
| Blade material | Tungsten steel/imported high speed steel |
| Power | 380W----600W |
| Power supply | AC175V－250≤50/60HZ |
| Dimension | 420mmx297mm x 345mm |
| Weight | 28KG |
